1100°F / 593°C High Temperature & Heat Resistant Fiberglass Woven LadderTapeä:
Heat, Flame & Fire Resistant and Thermal Insulating
Heat, Flame & Fire Resistant and Thermal Insulating
High Temperature Fiberglass Woven Tape
Top Photo: Plain tape
Bottom Photo: Drop warp (bolt-hole or ladder) tape
Top Photo: Plain tape
Bottom Photo: Drop warp (bolt-hole or ladder) tape
Catalog Page & Pricing
Premium Grade
Industrial Grade
Premium Thin
Extra Thick Premium
Extra Wide Premium
Premium Grade
Industrial Grade
Premium Thin
Extra Thick Premium
Extra Wide Premium
Part Numbers:
T-FG-W-P
T-FG-W-I
T-FG-W-P-T
T-FG-W-XTP
T-FG-W-EWP
T-FG-W-P
T-FG-W-I
T-FG-W-P-T
T-FG-W-XTP
T-FG-W-EWP
This high temperature tape is heat, flame and fire resistant. Fiberglass (fibreglass or glass-fibre) woven tapes are fabricated from high quality type E fiberglass that will not burn and will withstand continuous exposure to temperatures of 1100°F / 593°C.
These high temperature tapes provide protection of industrial wires, cables, hoses, tube and pipe and also provide thermal insulation and personnel protection. Also used as a gasket or seal. Available as a Plain tape or Drop-Warp tape (center longitudinal yarns missing), often called a bolt-hole tape or ladder tape.
This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is flexible and conformable. For a higher degree of flexibility and conformability, consider using a knitted version of this tape (knitted fiberglass tape).
Available thicknesses include 1/32", 1/16", 1/8", 1/4" and 9/32". These tapes are available with Pressure Sensitive Adhesive to aid in placing the tape.
The 9/32" tape is available meeting MIL-I-24244C (amend 1, IC 1, Type XVIII).
These high temperature tapes provide protection of industrial wires, cables, hoses, tube and pipe and also provide thermal insulation and personnel protection. Also used as a gasket or seal. Available as a Plain tape or Drop-Warp tape (center longitudinal yarns missing), often called a bolt-hole tape or ladder tape.
This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is flexible and conformable. For a higher degree of flexibility and conformability, consider using a knitted version of this tape (knitted fiberglass tape).
Available thicknesses include 1/32", 1/16", 1/8", 1/4" and 9/32". These tapes are available with Pressure Sensitive Adhesive to aid in placing the tape.
The 9/32" tape is available meeting MIL-I-24244C (amend 1, IC 1, Type XVIII).
Technical Specifications
Fiber Type: E Glass
Specific Gravity: 2.54-2.69
Breaking Tenacity: 1.71 gf/TEX. Std. 1.71 gf/TEX Wet
Effect of Heat: Will not burn; Retains 75% tensile at 343°C; Softens at 732-877°C; Melts at 1121-1182°C
Tensile Strength: 450,000-500,000 psi.
Effect of Acids and Alkalis; Resistance to acids is fair. Good resistance to most alkalis.
Breaking Elongation: 4.81% Std. 4.81% Wet
Elastic Recovery: 100%
Effect of Bleaches and Solvents: Unaffected
Average Stiffness: 2824.3 cn/TEX
Fiber Type: E Glass
Specific Gravity: 2.54-2.69
Breaking Tenacity: 1.71 gf/TEX. Std. 1.71 gf/TEX Wet
Effect of Heat: Will not burn; Retains 75% tensile at 343°C; Softens at 732-877°C; Melts at 1121-1182°C
Tensile Strength: 450,000-500,000 psi.
Effect of Acids and Alkalis; Resistance to acids is fair. Good resistance to most alkalis.
Breaking Elongation: 4.81% Std. 4.81% Wet
Elastic Recovery: 100%
Effect of Bleaches and Solvents: Unaffected
Average Stiffness: 2824.3 cn/TEX
Benefits of our High-Temperature Fiberglass Heat Protection Products
Fiberglass offers excellent heat resistance, retaining more than half of its room temperature tensile strength at 675°F / 357°C, and more than 25% at 875°F / 468°C. It begins to soften at 1500°F / 815°C and melts near 2050°F / 1121°C. Non-combustible and excellent thermal conductivity to dissipate hot spots; high resistance to chemicals and unaffected by UV light.
Fiberglass offers excellent heat resistance, retaining more than half of its room temperature tensile strength at 675°F / 357°C, and more than 25% at 875°F / 468°C. It begins to soften at 1500°F / 815°C and melts near 2050°F / 1121°C. Non-combustible and excellent thermal conductivity to dissipate hot spots; high resistance to chemicals and unaffected by UV light.
